| Mode |
R3KL1DA-G2A |
R3K6L1DA-G2A |
R4KL1DA-G2A |
R4K6L1DA-G2A |
R5KL1DA-G2A |
R6KL1DA-G2A |
| PV input data |
| Max. PV input power (kW) |
4.5 |
5.4 |
6 |
6.9 |
7.5 |
9 |
| Max. PV input voltage (V) |
500 |
| Min. PV input voltage (V) |
100 |
| Start-up voltage (V) |
100 |
| MPPT voltage range@full-load (V) |
140~425
|
170~425 |
190~425 |
216~425 |
234~425 |
281~425 |
| Rated PV input voltage (V) |
360 |
| No. of MPPT trackers |
2 |
| No. of strings per MPPT tracker |
1/1 |
| Max. input current per MPPT (A) |
16/16 |
| Max. short-circuit current per MPPT (A) |
24/24 |
| Battery input date |
| Battery type |
Lithium-ion / Lead-acid |
| Max. charge / discharge power (kW) |
3 |
3.68 |
4 |
4.6 |
5 |
6 |
| Battery voltage range (V) |
40-58 |
| Rated battery voltage (V) |
48 |
| Max. charging / discharging current (A) |
60/60 |
72/72 |
80/80 |
92/92 |
100/100 |
120/120 |
| Rated charge / discharge current (A) |
60/60 |
72/72 |
80/80 |
92/92 |
100/100 |
120/120 |
| Charging strategy for Li-Ion battery |
Self-adaption to BMS |
| BMS communication |
CAN |
