20000A Series Three -Phase 750Vac 20KW
Product Parameters
| Product Name |
LM400-750 |
| DC bus side |
| Rated output power |
20KW |
| Rated output current |
30-60A |
| Output voltage range |
200-750Vdc |
Efficiency
|
≥95%
|
| Battery-side |
| Voltage range |
30~100Vdc |
| Rated voltage |
60Vdc |
| Max Current |
105Amax |
| Power rating |
5kW |
| Steady-current accuracy |
≤±5% |
Current ripple
|
<5% |
Voltage ripple
|
<2% |
Standby consumption
|
<30W (Vbat=100Vdc, module dormant) |
| Rated input voltage |
Three-phase380Vac/480Vac |
| input Input voltage range |
23Vac~520Vac(Full load), 323Vac~260Vac |
| input Frequency |
45Hz~65Hz |
| Size |
220*82*440mm |
| Weight |
6KG |
