| Mode |
R5KLNA |
R6KLNA |
R7K6LNA |
R8KLNA |
R10KLNA |
| PV input data |
| Max. PV input power (kW) |
7.9 |
9 |
12 |
12 |
15 |
| Max. PV input voltage (V) |
500 |
| Min. PV input voltage (V) |
120 |
| Start-up voltage (V) |
120 |
| MPPT voltage range@full-load (V) |
120-500 |
| Rated PV input voltage (V) |
150-430 |
| No. of MPPT trackers |
4 |
| No. of strings per MPPT tracker |
1/1/1/1 |
| Max. input current per MPPT (A) |
14/14/14/14 |
| Max. short-circuit current per MPPT (A) |
22/22/22/22 |
| Battery input date |
| Battery type |
Lithium-ion / Lead-acid |
| Max. charge / discharge power (kW) |
5 |
6 |
7.6 |
8 |
10 |
| Battery voltage range (V) |
40-58 |
| Rated battery voltage (V) |
48 |
| Max. charging / discharging current (A) |
120/120 |
135/135 |
190/190 |
190/190 |
190/210 |
| Rated charge / discharge current (A) |
120/120 |
135/135 |
190/190 |
190/190 |
190/210 |
| Charging strategy for Li-Ion battery |
Self-adaption to BMS |
| BMS communication |
CAN |
