Model
|
SUN-5K
-SG04LP3-EU |
SUN-6K
-SG04LP3-EU |
SUN-8K
-SG04LP3-EU |
SUN-10K
-SG04LP3-EU |
SUN-12K
-SG04LP3-EU |
|||||
|
Battery Input Data
|
||||||||||
|
Battery Type
|
Lead-acid or Lithium-ion
|
|||||||||
|
Battery Voltage Range (V)
|
40-60
|
|||||||||
|
Max. Charging Current (A)
|
120
|
150
|
190
|
210
|
240
|
|||||
|
Max. Discharging Current (A)
|
120
|
150
|
190
|
210
|
240
|
|||||
|
Charging Strategy for Li-ion Battery
|
Self-adaption to BMS
|
|||||||||
|
Number of Battery Input
|
1
|
|||||||||
|
PV String Input Data
|
||||||||||
|
Max. PV Input Power (W)
|
6500
|
7800
|
10400
|
13000
|
15600
|
|||||
|
Max. PV Input Voltage (V)
|
800
|
|||||||||
|
Start-up Voltage (V)
|
160
|
|||||||||
|
MPPT Voltage Range (V)
|
200-650
|
|||||||||
|
Max. Continuous AC Passthrough (grid to load) (A)
|
45
|
|||||||||
|
Rated Input/Output Grid Frequency/Range(Hz
|
50/45-55, 60/55-65
|
|||||||||
|
Rated Input/OutputVoltage/Range (V)
|
220/380V, 230/400V 0.85Un-1.1Un
|
|||||||||
|
Efficiency
|
||||||||||
|
Max. Efficiency
|
97.6%
|
|||||||||
|
Euro Efficiency
|
97%
|
|||||||||
|
MPPT Efficiency
|
>99%
|
|||||||||
|
Grid Connection Form
|
3L+N+PE
|
|||||||||
|
Communication Interface
|
WIFI, RS485, CAN
|
|||||||||
|
Operating Temperature Range (℃)
|
-40 to +60℃, >45℃ Derating
|
|||||||||
|
Permissible Altitude
|
2000m
|
|||||||||
|
Noise (dB)
|
<55
|
|||||||||
|
Ingress Protection(IP) Rating
|
IP 65
|
|||||||||
|
Cabinet Size (WxHxD mm)
|
422×658×254 (Excluding Connectors and Brackets)
|
|||||||||
|
Weight (kg)
|
38
|
|||||||||
|
Warranty
|
5 Years/10 Years
|
|||||||||
|
Grid Regulation
|
IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002,
OVE-Richtlinie R25, G99, VDE-AR-N 4105 |
|||||||||
|
Safety / EMC Standard
|
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
|
|||||||||
