| Item | WT48XX | WT60XX | WT72XX | WT144XX | WT320XX |
| Rated voltage | 48V | 60V | 72V | 144V | 320V |
| Max output voltage | 68V | 85V | 102V | 168V | 400V |
| Max output current | 50A | 35A | 35A | 20A | 10A |
| Rated voltage AC | 185-270VAC；45-65Hz | ||||
| AC Input Max current | 13.5A @100VAC； 15.0A @220VAC | ||||
| PF | ≥0.99 | ||||
| EffIciency | ≥94% | ||||
| Noise | ≤45dB | ||||
| IP Rating | IP65 | ||||
| Weight |
5.8kg | ||||
| Operating Temperature |
-30~65℃ | ||||
| Storage Temperature |
-40℃~95℃ | ||||
| Comoliance |
UL/CB/CE/PSE/RCM/FCC/CEC/DOE/CP65 directives | ||||
| Rated voltage AC | 185-270VAC；45-65Hz |
| AC Input Max current | 13.5A @100VAC； 15.0A @220VAC |
| Comoliance | UL/CB/CE/PSE/RCM/FCC/CEC/DOE/CP65 directives |
| Weight | 5.8kg |
