| Item |
2KW TDC-K |
| Input voltage range |
240VDC~450VDC |
| Input under-voltage |
220VDC |
| Input over-voltage |
480VDC |
| Full load efficiency |
≥95% |
| Output voltage and current |
14Vdc±1%, 180A |
| Output power |
2.5KW |
| Protection mechanisms |
UVP (Under Voltage Protection)/OVP (Over Voltage Protection)/OCP (Over Current Protection)/SCP (Short Circuit Protection)/OTP (Over Temperature Protection) |
| Overload capacity |
>130% for 60 seconds continuously |
| Control mode |
Controlled via CAN bus or enable wire |
Protection functions
|
Output over-voltage protection, under-voltage protection, short-circuit protection, input reverse connection protection, over-temperature protection, and communication protection
|
Product dimensions
|
320 (length) x 245 (width) x 70 (height) (water-cooled)
|
Mechanical shock and seismic resistance grade
|
QC/T 895－2011
|
| Heat dissipation methods |
Water cooling, air cooling |
